The Terrain GX4s is a perfect example of a vehicle with unadulterated Off-Road DNA. Its powerful 570 EFI petrol engine and its 4×4 differential lock system, provide the Terrain GX4s with unmatched power. An authentic and ideally sized all-terrain vehicle.
Download spec sheet
Base
DX4 CAB CLIMA

MAKES WORK EVEN EASIER!

The DX4 equipment is designed for anyone looking for a simple vehicle with which to carry out any job comfortably. Fitted as standard with a large and versatile cargo box that allows you to carry everything you need for your working day.

Highlights:

  • Skid plate.
  • Rear differential lock.
  • Front receiver.
  • Tow ball rear.

Type approval: T1a and T1b.

HIGH LEVEL OF EQUIPMENT

The DX4 CAB CLIMA is the most equipped version of the TERRAIN range, and is specially designed to work hard in extreme conditions. Perform the toughest work under any conditions, thanks to the air conditioning and heating system.

Highlights:

  • HVAC and Heater system.
  • Courtesy light.
  • Front insulation panel.
  • Sist. front and rear hitch.

Type approval: T1a and T1b.

Dimensions

  • L x W x H: 3414 x 1656 x 1973 mm.
  • Ground clearance: 309 mm.
  • Towing capacity: 907 kg.
  • Cargo Box capacity: 450 kg.
  • Fuel capacity: 40 L.

Suspensions

  • Suspensions: Indep. double wishbone. 287 mm travel.
  • Damping: Gas shock-absorbers. Adjustableride height.
  • Anti-dive system.

Brakes and Tires

  • Front: 256 mm disk brakes with twin-piston calipers.
  • Rear: 220 mm disk brakes with single-piston calipers.
  • Handbrake: Yes, for back wheels and independent calipers.
  • Tires: Front 29×11. Steel rims R14.
  • Tires: Rear 16×11. Steel rims R14.

Engine

  • Yanmar diesel, 3 cylinder, 4 stroke.
  • 993 cc / 24 hp / 18 kw 3600 rpm
  • Water cooling
  • Gearbox: CVT. Clutch L-H-N-R
  • 4WD-2WD with rear differential lock

Features

  • Rigid full doors.
  • Courtesy light.
  • Front storage.
  • Front and rear receiver.

Homologation & Warranty

  • Homologation: Option T1a / T1b.
  • Person capacity: 2 pax.
  • Max speed EU: T1a: 40 km/h – T1b: 60 km/h.
  • Warranty: 2 years CE.

Dimensions

  • L x W x H: 3414 x 1656 x 1973 mm.

Dimensions

  • L x W x H: 3414 x 1656 x 1973 mm.

Dimensions

  • L x W x H: 3414 x 1656 x 1973 mm.

Dimensions

  • L x W x H: 3414 x 1656 x 1973 mm.

Dimensions

  • L x W x H: 3414 x 1656 x 1973 mm.

Dimensions

  • L x W x H: 3414 x 1656 x 1973 mm.

EQUIPMENT THAT ADAPTS TO YOUR NEEDS

MAKES WORK EVEN EASIER!

The DX4 equipment is designed for anyone looking for a simple vehicle with which to carry out any job comfortably. Fitted as standard with a large and versatile cargo box that allows you to carry everything you need for your working day.

Standard packages:

Base
Base EPS
Pro EPS
Cab
  • 2x4/4x4 system
  • Rear differential lock
  • Cargo bed
  • Skid plate
  • Roof
  • Adjustable seats
  • 3-point safety belt
  • Front hitch receiver
  • Rear 2” tow ball
  • Bottle storage
  • Mesh doors
  • 2x4/4x4 system
  • Rear differential lock
  • Cargo bed
  • Skid plate
  • Roof
  • Adjustable seats
  • 3-point safety belt
  • Front hitch receiver
  • Rear 2” tow ball
  • Bottle storage
  • Mesh doors
  • Electric power steering EPS
  • 2x4/4x4 system
  • Rear differential lock
  • Cargo bed
  • Skid plate
  • Roof
  • Adjustable seats
  • 3-point safety belt
  • Front hitch receiver
  • Rear 2” tow ball
  • Bottle storage
  • Mesh doors
  • Electric power steering EPS
  • Front windscreen
  • Front wiper system
  • Rear screen
  • Inner rearview mirror
  • 2x4/4x4 system
  • Rear differential lock
  • Cargo bed
  • Skid plate
  • Roof
  • Adjustable seats
  • 3-point safety belt
  • Front hitch receiver
  • Rear 2” tow ball
  • Bottle storage
  • Mesh doors
  • Electric power steering EPS
  • Front windscreen
  • Front wiper system
  • Rear screen
  • Inner rearview mirror
  • Courtesy light
  • Heating

DIMENSIONS / CAPACITIES

  • L x W x H: 2650 x 1449 x 1930 mm.
  • Wheelbase: 1806 mm.
  • Ground clearance: 242 mm.
  • Dry weight: 626 kg.
  • Towing capacity: 869 kg.
  • Max. total load capacity: 440 kg.
  • Fuel capacity: 37,5 l.

Engine

  • Type: 570 EFI petrol, single-cylinder 4-stroke. 561 cc
  • Cooling: Liquid
  • Power: 42 cv / 31.4 kW / Electronic injection
  • Engine torque: 53.6 Nm / 5,500 rpm
  • Gearbox: Automatic CVT
  • Transmission: Automatic variator, L/H/N/R/P
  • 2×4/4×4 traction. Rear differential lock
  • EPS electric power steering
  • Maximum speed: EU: T1a: 40 km/h, T1b: 60 km/h

Homologation

  • EU T1a / T1b

CHASSIS

  • Front tire: 26×9, R12
  • Rear tire: 26×11, R12
  • Rims: 12” steel
  • Turning radius: 2,99 m
  • Suspension: Both McPherson struts with 205 mm travel
  • Brakes: Both 166 mm hydraulic disc
  • Hand brake: Disc. Actuates in transmission
  • Protection: Underbody guard
  • Coupling: Front hitch adapter and 2” rear ball
  • Lighting: LED (rear)
  • No. passengers: 2

CARGO BOX

  • Dimensions (L x W x H): 900 x 1191 x 300 mm
  • Material: Steel
  • Load capacity: 250 kg
Download spec sheet

NEW CHASSIS THAT KEEPS THE COMFORT IN THE CABIN

The CORVUS development team worked on this new chassis with one clear objective in mind: to maintain the habitability of the vehicle cabin.

The proportional dimensions of this UTV’s cabin are one of its strong points. In two words, roomy and spacious. In addition, its ergonomic and intuitive driving position offers the worker a surprising level of comfort and a smooth driving experience that make for a satisfying working day.

The most agile work vehicle

The size and qualities of the new Terrain GX4s combine to make it a nimble, easy-to-drive UTV that delivers perfect handling on all types of trails. With a ground clearance of 242 mm, and a turning radius of 2.99 m, the GX4s is more than able to negotiate all types of terrain.

Ideal compact size

The compact dimensions of the Terrain GX4s greatly increase this UTV’s versatility.With a width of 144.9 cm, it’s perfect for service tasks, but it can also be used in woodland areas. A perfect size that goes hand in hand with a maximum total load capacity of 440 kg – a leader in its class.

Easy to drive and maintain

As is the case with all the vehicles in the CORVUS family, maintaining the Terrain GX4s is an extremely simple task. To gain access to the engine assembly, the oil and air filters, and the CVT belt, all you need to do is remove the cargo box in one swift movement.
CONTACT US TO ARRANGE A TEST DRIVE
